ZYS High-efficiency Oil-water Separator | Excellent Technical Performance and Wide Applicability | Industrial Degreaser Manufacturing
- Model
- ZYS
Item specifics
- Air Processing Capacity
- 1〜500Nm³/min
- Operating Pressure
- 0.6〜1.0MPa
- Rated Air Inlet Temperature
- ≤50℃(Min 5℃)
- Filtration Pore Diameter
- ≤5μm
- Residual Oil Content
- ≤1ppm
- Steam-liquid Separation Efficiency
- 98%
- Pressure Drop between Air Inlet and Outlet
- ≤0.02MPa
- Environmental Temperature:
- ≤45℃
- Filter Element
- Adopt the filter material imported from DH Company
- Service Life
- ≥8,000h
Review
Description
ZYS is mainly composed of container parts, spiral separators, filter element parts, instruments and automatic pollutant discharge devices. The compressed air containing lots of oil, water and solid particles tangentially enters the spiral passageway after the diameter change and acceleration. Most of liquid drop and larger participles are removed due to the centrifugal effect. The pretreated compressed air can only enter the inner cavity of the spiral separator due to the obstruction by the middle tray, and pass through the cylinder-shaped filter element from outside to inside. The separator may further collect the tiny vaporific particles, and generate cohesion, to achieve gas-liquid separation.
This series high-efficiency oil-water separator is the new-generation compressed air secondary purification (gas-water separation and filtration) device developed by the company, with excellent technical performance and wide applicability, able to be installed in the rear of the compressor and after-cooler, in the front of the refrigerated dryer and adsorption dryer, or on the main pipe of general industrial gas, and carry out the effective separation and filtration for pollutants (oil, water and dust) in the compressed air.
Technical Indexes
Air Processing Capacity: 1~500Nm3/min
Operating Pressure: 0.6-1.0MPa (able to provide the product in the range of 1.0-3.0MPa according to the user requirements)
Air Inlet Temperature: w50°C (Min 5°C)
Filtration Pore Diameter: ≤5μm
Residual Oil Content: ≤1ppm
Steam-liquid Separation Efficiency: 98%
Pressure Drop between Air Inlet and Outlet: ≤0.02MPa
Environmental Temperature: ≤45°C
Filter Element: Adopt the filter material imported from DH Company
Service Life: ≥8,000h
