ZLY High-efficiency Oil Removal Device | Air Compressor Oil Removal Equipment | Industrial Degreaser Manufacturing
- Model
- ZLY
Item specifics
- Air Processing Capacity
- 1〜500Nm³/min
- Operating Pressure
- 0.6〜1.0MPa
- Rated Air Inlet Temperature
- ≤50℃(Min 5℃)
- Residual Oil Content
- ≤0.01PPm
- Steam-liquid Separation Efficiency
- 99.9%
- Pressure Drop between Air Inlet and Outlet
- ≤0.02MPa
- Environmental Temperature:
- ≤45℃
- Filter Element
- Adopt the filter material imported from DH Company
- Service Life
- ≥8,000h
Review
Description
High efficiency oil removal device is a filter with an integration of three purification stages like cyclone separation, coarse filtration and fine filtration, carries out the direct interception for oil and water in the air, and performs the filtration through cyclone separation, gravity sedimentation, coarse filtration and fine filter element layer, so as to completely remove the oil, water and dust in the compressed air. For the compressed air passing through this filter, the filtration precision may reach 0.1 μm, and the residual oil volume is less than 0.1 PPm.
Technical Indexes
Air Processing Capacity: 1~500Nm3/min
Operating Pressure: 0.6-1.0MPa (able to provide the product in the range of 1.0-3.0MPa according to the user requirements)
Air Inlet Temperature: ≤50°C (Min 5°C)
Oil Content of the Outlet Gas: ≤0.01PPm
Steam-liquid Separation Efficiency: 99.9%
Pressure Drop between Air Inlet and Outlet: ≤0.02MPa
Environmental Temperature: ≤45°C
Filter Element: Adopt the filter material imported from DH Company
Service Life: ≥8,000h
